STANVER CRUSHER - 1600 M with side-mounted engines

Main > Offers > Products > Industrial equipment > Mining equipment > Crushers >

Delivery regions

Russia

OKPD code

28.92.40.124Rotary crushers

VAT

VAT 22%

Brand name

Stanver

Manufacturer

DTM LLC

Country of origin

Russia

Unit of measurement

Piece

The method of obtaining

Delivery

Condition

New

Year of release

2023

At the current exchange rate of the Central Bank of the Russian Federation

13020000 —

156325.42 —

133622.88 —

114734.28 —

466162.08 —

574104.45 —

1051246.24 —

7491584.91 —

24821370.02 —

14964382.01 —

7945758.91 —

14964382.01 —

13020000 —

excluding shipping costs

STANVER CRUSHER - 1600 M is a model of a centrifugal crusher designed for crushing ore and non-metallic raw materials to obtain an initial fraction with a grain size of up to 70 mm (no more). The device is designed for dry processing of non-explosive materials.
Overall dimensions, mm. assembled with frame

- length : 3500
- width : 3500
- height : 3700

Weight, t: 12.

Installed capacity of the electric motor of the crusher drive, kW : 250 / 315
Synchronous speed of the shaft of the electric motor of the crusher drive, rpm: 1000
Rated current consumed by the crusher drive motor, A: 445 / 550
Installed power of the boost fan motor, kW: 37 (45)
Synchronous speed of the boost fan motor shaft,
rpm: 3000
Supply voltage, V : 380
Frequency, Hz: 50
Number of phases: 3
